IVO 14.1inch M141NWW1-103 LCD Panel

Place of Origin : Japan

Brand Name : IVO

Certification : RoHS Compliant

Model Number : M141NWW1-103

MOQ : 1 Pcs

Price : Pls Contact sales team

Packaging Details : MODULE

Delivery Time : stock

Payment Terms : T/T , Paypal, Western Union Escrow etc.

Supply Ability : 1000

Panel Model : M141NWW1-103

Panel Brand : IVO

Descrition : a-Si TFT-LCD ,14.1 inch, 1280×800

Panel Type : a-Si TFT-LCD

Contact Now

IVO 14.1inch M141NWW1-103 LCD Panel

Specification for M141NWW1-103:

M141NWW1-103 Basic Information

Panel Model

M141NWW1-103

Panel Brand

IVO

Descrition

a-Si TFT-LCD ,14.1 inch, 1280×800

Panel Type

a-Si TFT-LCD

Operating Temperature

0 ~ 50 °C

Storage Temperature

-20 ~ 60 °C

Remarks

VESA Compatible

M141NWW1-103 Mechanical Features

Dot Resolution

1280(RGB)×800 (WXGA)

Pixel Configuration

RGB Vertical Stripe

Pixel Density

107 PPI

Aspect Ratio

16:10 (H:V)

Form Factor

Flat Rectangle Display

Dot Pitch

0.079×0.237 mm (H×V)

Pixel Pitch

0.237×0.237 mm (H×V)

Weight

400g (Max.)

Surface

Glare (Haze 0%), Hard coating

Active Area

303.36×189.6 mm (H×V)

Bezel Area

307.4×193.6 mm (H×V)

Outline Dimension

319.5×205.5 mm (H×V)

Outline Depth

5.5 (Typ.) mm

Shape Style

Wedge (PCBA Bent, Depth ≥5.2mm)

Holes & Brackets

Side mounting holes (8-M2) on left, right bezel

Landscape or Portrait

Landscape type

Touch Panel

Without

M141NWW1-103 Optical Features

Display Mode

TN, Normally White, Transmissive

Brightness

200 cd/m² (Typ.)

Contrast Ratio

350 : 1 (Typ.) (Transmissive)

Display Color

262K (6-bit)

Response Time

8 (Typ.)(Tr+Td)

Viewing Angle

45/45/20/45 (Typ.)(CR≥10) (L/R/U/D)

Viewing Direction

6 o'clock

White color Chromaticity

Wx:0.313; Wy:0.329

White Variation

1.18/1.33 (Typ./Max.)(5 points)

Sunlight Readable

N

M141NWW1-103 Electronics Feature

Vertical Frequency

60Hz

Reverse Scan

No

Total Power Consumption

5.4W (Typ.)

M141NWW1-103 Backlight System

Lamp Position

Edge light type (Bottom side)

Lamp Type

CCFL

Lamp Amount

1 pcs

Lamp Shape

Straight

Lamp Life Time

15K(Min.) (Hours)

Lamp Voltage

655±65V

Lamp Current

6.0mA (Typ.)

Lamp Operating Frequency

50KHz (Typ.)

Lamp Startup Voltage

1200/1320V (Min.)(Ta=+25/0℃)

Interface Type

Connector

Lamp Driver Board

No

M141NWW1-103 Signal Interface

Signal Category

LVDS

Signal Class

LVDS (1 ch, 6-bit)

Input Voltage for Panel

3.3V (Typ.)

Input Current for Panel

0.27A (Typ.)

Interface Type

Connector

Signal Interface

JAE - FI-XB30SRL-HF11, Pitch:1.0 mm, Pin:30 pins
